Titanium Grade 1 substrate, purity ≥99.6%, excellent corrosion resistance under typical CP conditions
MMO coating thickness 8–15 μm, stable performance at current densities 50–100 A/m²
Operating current density 50–100 A/m², suitable for soil and seawater protection
Design life up to 20 years under standard CP environments
Consumption rate 0.5–1 mg/A·year, minimizing material loss over lifetime
Typical working voltage 1.5–3.5 V, optimized for energy-efficient systems
Custom linear lengths up to 1000 m, ensuring uniform current distribution

Coating Loading: 6 – 15 g/m²
Current Density: 500 – 2000 A/m²
Operating Voltage: 1.1 – 1.4 V
Lifespan: Approx. 1 – 5 years
Substrate: Gr1 / Gr2 Titanium
Working Medium: NaCl / Seawater / Brine / Electroplating solutions

Coating thickness ≥2 μm with high electrocatalytic activity
Low consumption rate: 1–6 mg/A·a for long-term stability
Design life up to 30–50 years in harsh environments
Output current range: 17–86 mA/m depending on specification
Standard size: 6.35 mm width × 0.635 mm thickness
Coil length options: 76.2 m or 152 m per roll
