1/2"-20 Titanium Wheel Nut

Product Overview

The 1/2"-20 Titanium Wheel Nut is a high-strength, lightweight fastener engineered for performance vehicles, muscle cars, and classic American cars that use imperial thread studs. Made from aerospace-grade Grade 5 titanium alloy (Ti-6Al-4V), it provides excellent mechanical strength, superior corrosion resistance, and a significant reduction in unsprung weight compared to traditional steel lug nuts. This wheel nut is ideal for both racing and daily driving applications where durability and weight savings matter.

---

Key Specifications

• Product Name: 1/2"-20 Titanium Wheel Nut

• Thread Size: 1/2" UNF (20 threads per inch)

• Material: Grade 5 Titanium Alloy (Ti-6Al-4V)

• Hex Size: 3/4" (19mm) or 13/16" (21mm)

• Seat Type: 60° Conical (standard), Ball Seat (optional)

• Overall Length: 1.38" (35mm) or custom

• Finish Options:

  • Raw Titanium

  • Burnt Blue / Gold

  • Anodized (Black, Purple, Rainbow, etc.)

• Head Style: Closed-End or Open-End

• Tensile Strength: ≥ 950 MPa

• Weight: Approx. 22g–26g per piece

• Manufacturing Process: CNC Precision Machining or Hot Forging

• Standards Compliance: ANSI / SAE / Custom OEM spec

---

Product Features

• Aerospace-Grade Titanium: Manufactured from Ti-6Al-4V alloy for superior tensile strength, fatigue resistance, and thermal stability

• Lightweight Construction: Reduces unsprung and rotational mass, improving acceleration, braking, and suspension responsiveness

• Excellent Corrosion Resistance: Suitable for harsh weather, salt exposure, and long-term outdoor use without rusting

• Accurate Thread Fit: Precision-machined internal threads ensure a secure fit on 1/2"-20 studs used in many American vehicles

• Aesthetic Variety: Offered in a range of anodized and heat-treated finishes to match vehicle styling

• Ideal Compatibility: Fits most classic American cars, drag racing vehicles, off-road trucks, and muscle cars with imperial wheel studs

• Heat Resistant: Performs reliably under extreme temperatures from high-performance brake systems

Application Areas

1. Racing Cars
Widely used in professional motorsport environments including circuit racing, time attack, drag racing, and drift competitions. The high strength and low weight help reduce unsprung mass and increase wheel responsiveness.

2. Performance Street Vehicles
Ideal for high-performance street cars that demand both visual appeal and technical performance. Titanium lug nuts provide enhanced aesthetics while maintaining structural integrity under daily and spirited driving.

3. Aftermarket Wheels
Perfect for forged and lightweight alloy wheels which benefit from the reduced weight of titanium hardware. Ensures precise fitment and complements premium wheel finishes.

4. Custom Builds and Tuning Projects
Popular among car modification enthusiasts for custom cars, show builds, and tuning upgrades. Titanium’s customizable finishes allow unique styling that stands out at car meets and expos.

5. Supercars and Exotic Vehicles
Trusted by owners of high-end brands such as Ferrari, Lamborghini, Porsche, McLaren, and more. Titanium lug nuts ensure that both performance and durability match the level of these vehicles.

6. Off-Road and Rally Vehicles
Used in demanding off-road conditions where strength, corrosion resistance, and reliability are critical. Titanium’s lightweight nature also benefits vehicles tackling extreme terrain and rapid wheel changes.

7. Brake-Intensive Driving Conditions
Suitable for use in vehicles with high-performance brake systems, where titanium’s heat resistance ensures structural stability even under extreme temperatures caused by repeated hard braking.

OEM and Custom Services

Custom thread pitch and seat type
Available in raw titanium or anodized colors
Laser engraved logos or part numbers
Retail-ready packaging with private label
Titanium wheel stud kits available upon request

Modification and customization physical display：

Grooved closed-end automobile wheel nuts：M12x1.5 M12x1.25 M14x1.5 M14x1.25--45mm

Side hole hollow car wheel nuts：M12x1.5 M14x1.5 M14x1.25--45mm

Non-slip knurled hollow car wheel nut：M12x1.5 M14x1.5 M14x1.25--45mm

Hexagon socket wrench for automobile wheel nuts：M12x1.5 M14x1.5 M14x1.25--35/45/50/60mm

Eccentric gasket automobile wheel nuts:M12x1.5 M12x1.25 M14x1.5 M14x1.25--35mm

Ball pad closed hexagon anti-theft car wheel nuts:M12x1.5--35mm

Spherical gasket closed knurled anti-theft automobile wheel nuts:M12x1.5-48mm

Spherical anti-theft closed-end automobile wheel nuts:M12x1.5-35mm

Spherical knurled non-moving gasket automobile wheel nut：M12x1.5-35mm



Spherical open automobile wheel nuts:M12x1.5-45mm

Spherical open semi-hollow automobile wheel nuts:M12x1.5--35mm

Spherical open hollow automobile wheel nuts:M12x1.5--35mm

Spherical Washer Automobile Wheel Nuts:M12x1.5--45mm

Spherical modified car wheel nuts:M14X1.5--45mm

External plum anti-theft car wheel nuts:M14x1.5 M14x1.25 M12x1.5--35mm

Duckbill ball anti-theft car wheel nut：M14x1.5 M12x1.5 M12x1.25--35mm

Conical hexagonal open automobile wheel nut：M12x1.25--27 37 45mm

Customized according to the following drawings：

---

Technical Specifications

Property	Value
Tensile Strength	≥ 895 MPa (Gr5)
Yield Strength	≥ 828 MPa (Gr5)
Density	4.43 g/cm³
Hardness	36 HRC (Approx.)
Thread Tolerance	6g/6H ISO Metric or UNF/UNC

APPLICATION	NUT SEAT TYPE	NUT SIZE	NUT WEIGHT (g)	THREAD PITCH
Audi & Volkswagen	R13 Ball (OEM-Style)	19mm Hex Long	22.9	1.50P
Audi & Volkswagen	R13 Ball (OEM-Style)	19mm Hex Long	22.9	1.50P
Audi & Volkswagen	R13 Ball (OEM-Style)	19mm Hex Long	22.9	1.50P
Audi & Volkswagen	R13 Ball (OEM-Style)	19mm Hex Long	22.9	1.50P
Audi & Volkswagen	R13 Ball (OEM-Style)	19mm Hex Long	22.9	1.50P
Audi & Volkswagen	60° Cone (Aftermarket)	19mm Hex Long	22.9	1.50P
Audi & Volkswagen	60° Cone (Aftermarket)	19mm Hex Long	22.9	1.50P
Audi & Volkswagen	60° Cone (Aftermarket)	19mm Hex Long	22.9	1.50P
Audi & Volkswagen	60° Cone (Aftermarket)	19mm Hex Long	22.9	1.50P
Audi & Volkswagen	60° Cone (Aftermarket)	19mm Hex Long	22.9	1.50P
BMW & MINI	60° Cone (OEM-Style)	E24 Torx	22.9	1.50P
BMW & MINI	60° Cone (OEM-Style)	E24 Torx	22.9	1.50P
BMW & MINI	60° Cone (OEM-Style)	E24 Torx	22.9	1.50P
BMW & MINI	60° Cone (OEM-Style)	E24 Torx	22.9	1.50P
BMW & MINI	60° Cone (OEM-Style)	E24 Torx	22.9	1.50P

---

Dimensional Capabilities

Thread Sizes: M12,M14, 1/2"-20 UNF

Length Options: 25-60mm, customized sizes available

Seat Type: cone seat、ball seat、tuner、Flat

Type:Ordinary titanium nut、Titanium nut with lock and anti-theft function

---

To provide you with an accurate quotation, please kindly fill out the details below and submit the form.
The more complete the information, the faster and more precise our response will be.

Please include the following:

Product Name: __________________________

Dimensions: Inner Diameter _______ × Outer Diameter _______ × height _______

Order Quantity: _______ pcs

Surface Treatment: __________________________

Material: __________________________

Required Delivery Time: __________________________

Shipping Destination: __________________________ (Please include country and postal code)

Drawing File: Please email your design (JPEG, PNG, PDF, or Word format) with a minimum resolution of 300 DPI to ensure clarity.

Product Quality Management

Production and Processing

Workshop and Equipment

Packaging and Delivery

Standard packaging includes foam tray and export carton
Custom retail packaging options available
Lead time is 5 to 10 days for stock sizes and 10 to 20 days for custom sizes
Shipping available via DHL FedEx UPS air freight or sea freight
Global export support with full documentation

Main Products

FAQ

1. What makes titanium a good choice for wheel nuts?

Titanium is strong, lightweight, and highly resistant to corrosion, making it ideal for demanding applications like automotive, aerospace, and marine.

2. Can the 1/2"-20 Titanium Wheel Nut be customized?

Yes, we offer customization options for thread sizes, surface finishes, and packaging based on your specific requirements.

3. What is the typical lead time for an order?

Lead times typically range from 2-4 weeks, depending on the order size and customization requirements.

4. Are your products certified?

Yes, our products are manufactured to meet ASTM, ASME, ISO, and JIS standards and are ISO9001:2015 certified.

---
