titanium alloy plate gr5
2.Lightweight design, perfect for aerospace and marine industries.
3.Superior surface finish for reliable industrial applications.
4.Excellent weldability and formability for custom projects.
5.Precision thickness control ensures consistent performance.
Titanium Alloy Plate Gr5: Premium Quality for High-Performance Applications
Introduction
Baoji Haiyue New Metal Materials Co., Ltd. is proud to offer Titanium Alloy Plate Gr5, a premium material known for its strength, lightweight properties, and resistance to corrosion. This versatile alloy, primarily made of titanium, aluminum, and vanadium, is widely used across high-performance industries like aerospace, medical devices, energy, and marine engineering. Our Titanium Alloy Plate Gr5 is crafted to meet the highest international standards, ensuring reliability and performance in critical applications.
Technical Specifications
General Specifications of Titanium Alloy Plate Gr5
| Property | Specification |
|---|---|
| Alloy Grade | Gr5 (Ti-6Al-4V) |
| Density | 4.43 g/cm³ |
| Melting Point | 1,660°C |
| Tensile Strength | 895 MPa |
| Yield Strength | 828 MPa |
| Elongation | 10% |
| Modulus of Elasticity | 113.8 GPa |
| Hardness (Brinell) | 334 HB |
| Electrical Resistivity | 0.4 µΩ·m |
Production Standards for Titanium Alloy Plate Gr5 (US, Russian, and Japanese Grades)
| Country | Standard | Grade |
|---|---|---|
| USA | ASTM B265, AMS 4911 | Ti-6Al-4V |
| Russia | GOST 19807-91 | VT6 |
| Japan | JIS H 4600 | Ti-6Al-4V |
Chemical Composition of Titanium Alloy Plate Gr5
| Element | Composition (%) |
|---|---|
| Titanium (Ti) | 90.2 - 94.0 |
| Aluminum (Al) | 5.5 - 6.75 |
| Vanadium (V) | 3.5 - 4.5 |
| Iron (Fe) | ≤ 0.3 |
| Oxygen (O) | ≤ 0.2 |
| Carbon (C) | ≤ 0.08 |
| Nitrogen (N) | ≤ 0.05 |
| Hydrogen (H) | ≤ 0.015 |
 |
 |
 |
 |
 |
 |
 |
 |
Product Features
- High Strength-to-Weight Ratio: Titanium Alloy Gr5 offers exceptional strength while being significantly lighter than steel, making it ideal for industries where weight is critical.
- Corrosion Resistance: It exhibits outstanding resistance to corrosion, even in harsh environments such as seawater or acidic conditions.
- Biocompatibility: Perfect for medical and healthcare applications, it is non-toxic and does not cause adverse reactions in the human body.
- Heat Resistance: This material can withstand high temperatures, making it suitable for aerospace and industrial applications.
- Fatigue Resistance: Titanium Gr5 is highly resistant to fatigue and can endure extreme pressure, vibration, and cycling stresses.
- Customizable: Available in various sizes and thicknesses, Gr5 plates can be tailored to specific requirements.
Applications
Titanium Alloy Plate Gr5 serves a multitude of industries and applications:
- Aerospace and Aviation: Used in aircraft structural components, turbine blades, and engine parts.
- Medical Devices and Healthcare: Ideal for implants, prosthetics, and surgical instruments due to its biocompatibility and corrosion resistance.
- Chemical Processing: Used for reactors, heat exchangers, and other equipment exposed to aggressive chemicals.
- Energy Sector: Essential for nuclear reactors, wind turbines, and other energy applications where materials must withstand extreme conditions.
- Marine Engineering: Perfect for shipbuilding and offshore oil rigs due to its resistance to saltwater corrosion.
- Industrial Manufacturing: Found in high-performance tools, fasteners, and industrial machinery components.
Manufacturing Process
Our Titanium Alloy Plate Gr5 is produced using state-of-the-art facilities. The process involves:
- Material Sourcing: High-quality titanium sponge is sourced from trusted suppliers.
- Hot Rolling: The titanium is heated and rolled into slabs, plates, or coils.
- Cold Rolling and Forging: The material is further processed to achieve desired dimensions.
- Heat Treatment: Plates are heat-treated to enhance their mechanical properties.
- Surface Finishing: A smooth and uniform surface is achieved through polishing and cleaning processes.
- Quality Control: Every batch undergoes rigorous testing to ensure compliance with international standards.
Quality Assurance
At Baoji Haiyue, we uphold the highest quality standards:
- Certifications: ISO 9001:2015, AS9100D, and GJB9001C:2007 ensure our products meet global quality benchmarks.
- Testing Methods: We employ advanced testing methods such as ultrasonic testing, eddy current testing, and spectral analysis to guarantee the quality of each product.
- In-house Labs: Our in-house laboratories are equipped with cutting-edge technology for material analysis and testing.
Every Titanium Alloy Plate Gr5 is thoroughly inspected for consistency and performance, ensuring it meets the stringent demands of high-performance industries.
Packaging and Logistics
- Packaging: Each titanium alloy plate is carefully packaged to prevent damage during transportation. Custom packaging options are available for large orders.
- Logistics: We offer reliable delivery options worldwide. Fast delivery ensures your project timelines are met, and our global network ensures cost-effective transportation.
Customer Support
Our dedicated customer support team is here to assist you at every step of the process:
- Product Inquiries: Detailed product specifications and expert guidance.
- Order Support: Seamless ordering process and tracking.
- After-Sales Service: Timely follow-ups to ensure customer satisfaction.
Why Choose Us?
- Complete Product Range: We offer a comprehensive range of titanium alloys, including Gr5, ensuring you have access to a broad selection of high-performance materials.
- Full-Process Production: From raw materials to finished products, we control the entire production process to ensure superior quality.
- Customized Solutions: Tailored products to meet the specific needs of industries such as aerospace, medical, and energy.
- Global Reach: Serving over 20 countries worldwide, we have built a reputation for reliability and quality.
- Fast Delivery: We guarantee quick lead times, ensuring you receive your products on schedule.
- Competitive Pricing: We offer cost-effective solutions without compromising on quality.
- Customer-Centric Service: Our team provides exceptional support and technical expertise for all your material needs.
Development History
Company founded in Baoji, "Titanium Valley," specializing in titanium and non-ferrous metals.
Expanded product range to include zirconium, tantalum, nickel, tungsten, and molybdenum products.
Achieved ISO9001:2015 certification, ensuring high-quality production standards.
Upgraded manufacturing facilities, adding VAR furnaces, CNC machinery, and advanced heat treatment systems.
Expanded global presence, establishing partnerships in the United States, Germany, and South Korea.
Obtained AS9100D certification for aerospace industry compliance and advanced product quality.
Introduced customized solutions for the aerospace, medical, and energy industries, enhancing global reach.
Celebrated 14 years of excellence with over 2,000 tons of annual titanium production capacity.
Product Quality Management
Production and Processing
Workshop and Equipment
Packaging
Main Products
Applied Industries
Be used in a wide range of industries.
Electrolytic copper foil manufacturing industry
Hydrometallurgy industry
Sewage treatment industry
Cyclone electrolysis industry
Etching liquid electrolysis recovery industry
Electrolytic sodium hypochlorite industry
OEM Services
We understand the importance of customized solutions, and our OEM services are designed to cater to your specific requirements. Whether you need custom sizes, shapes, or unique specifications, we can tailor our Titanium Alloy Plate Gr5 to suit your needs.
Frequently Asked Questions (FAQs)
1. What industries use Titanium Alloy Plate Gr5? Titanium Alloy Gr5 is used in aerospace, medical devices, energy, chemical processing, marine engineering, and industrial manufacturing.
2. How do I ensure the material meets my specific requirements? We offer customizable sizes and thicknesses, and our technical support team is available to assist with material selection.
3. Is Titanium Alloy Plate Gr5 resistant to corrosion? Yes, it offers outstanding resistance to corrosion, especially in harsh environments like seawater and chemicals.
4. Can I get a quote for bulk orders? Yes, we provide competitive pricing for bulk orders. Contact us for a tailored quote.
